## TL;DR
I designed and built **CodeNova**, a scalable coding interview platform handling 10K+ concurrent users with three AI-powered features: **video avatar tutor**, **algorithm visualizer**, and **collaborative whiteboard**. This is a deep dive into the system architecture and design decisions.

---

{% youtube BlJtQZ85rnw %}

## 🎯 What is CodeNova?

CodeNova is an AI-enhanced coding interview platform designed for scalability and learning. Core features include:
- **155+ problems** across multiple difficulty levels
- **10+ programming languages** with sandboxed execution
- **AI video tutor** with realistic avatar and natural voice
- **Automatic algorithm visualization** for any code
- **Real-time collaborative whiteboard** for mock interviews
- **Contest leaderboards** with analytics

**Scale:** Built to handle **10,000 concurrent users**, **1,000 submissions/minute**, with **99.9% uptime**.

---

## 🏗️ High-Level Architecture

![CodeNova Architecture](https://dev-to-uploads.s3.amazonaws.com/uploads/articles/46evcoh1sk21eclygwr1.png)

### System Overview

The architecture follows a **microservices-ready design** with clear separation of concerns across 6 layers:

```
Layer 1: Client (Browser)
    ↓
Layer 2: CDN & Load Balancing (CloudFlare + Nginx)
    ↓
Layer 3: Application Tier (Next.js + Express + Socket.io)
    ↓
Layer 4: Data Tier (MongoDB + Redis + PostgreSQL)
    ↓
Layer 5: Queue Layer (BullMQ)
    ↓
Layer 6: Workers & External Services (Judge0, Gemini AI, ElevenLabs, ANAM)
```

---

## 🌟 Three Unique Features - Architecture Breakdown

### 1. AI Video Avatar Tutor

**The Challenge:**
How do you provide personalized video explanations to thousands of users without hiring human tutors?

**The Solution: Three-Stage Pipeline**

```
User Question → Gemini AI → ElevenLabs → ANAM AI → Cached Video
              (Text Gen)   (TTS)        (Avatar)
```

**Architecture Decisions:**

**Decision 1: Why Three Separate Services?**
- **Gemini AI** - Best at generating educational content
- **ElevenLabs** - Most natural-sounding TTS (better than AWS Polly)
- **ANAM AI** - Realistic lip-sync (alternatives: D-ID, Synthesia)

**Trade-off:** Higher complexity but better quality. Users prefer natural voice over robotic TTS.

**Decision 2: Caching Strategy**
- **Problem:** Generating avatar videos takes 30 seconds per request
- **Solution:** Redis cache with 24-hour TTL for common questions
- **Result:** 70% cache hit rate significantly reduces generation load

**Decision 3: Async Processing**
- **Why:** 30-second generation time blocks API
- **How:** BullMQ job queue
- **Benefit:** User sees loading screen, gets notification when ready

---

### 2. AI-Powered Algorithm Visualizer

**The Challenge:**
Traditional visualizers need manual step creation for each algorithm. How to support ANY algorithm without manual work?

**The Solution: AI-Generated Visualization Steps**

```
User Code → Gemini AI → JSON Steps → Canvas Renderer → Interactive Visualization
         (Analyze)    (Generate)    (Frontend)
```

**Architecture Decisions:**

**Decision 1: Why AI Over Templates?**
- **Templates approach:** 155+ algorithms × manual steps = months of work
- **AI approach:** Gemini analyzes ANY code automatically
- **Trade-off:** API dependency vs. automatic generation at scale

**Decision 2: Where to Render?**
- **Server-side rendering:** High CPU usage, poor UX
- **Client-side (Canvas API):** Better performance, lower server load
- **Chosen:** Client-side with JSON steps from server

**Decision 3: Data Format**
Gemini returns structured JSON:
```
Step format:
- Description (plain English)
- Array state at this step
- Elements to highlight
- Comparison pointers
```

**Supported Algorithms:**
- Sorting: Bubble, Merge, Quick, Heap, Insertion
- Searching: Binary, Linear, DFS, BFS
- Data Structures: Stack, Queue, Trees, Graphs
- DP: Fibonacci, Knapsack, LCS with table visualization

---

### 3. Collaborative Whiteboard

**The Challenge:**
Enable real-time drawing for multiple users in mock interviews.

**The Solution: WebSocket + Pub/Sub Architecture**

```
User A draws → Socket.io Server → Redis Pub/Sub → All Users in Room
                     ↓
                 MongoDB (persist)
```

**Architecture Decisions:**

**Decision 1: WebSocket vs. Polling?**
- **Polling:** Simple but wasteful (10K users × 5s intervals = 2K QPS)
- **WebSocket:** Persistent connection, instant updates
- **Chosen:** Socket.io for fallback support (WebSocket → long polling)

**Decision 2: How to Scale WebSockets Across Multiple Servers?**
- **Problem:** User A on Server 1, User B on Server 2
- **Solution:** Redis Pub/Sub for cross-server communication
- **How it works:**
  - Server 1 publishes draw event to Redis
  - Server 2 subscribes and receives event
  - Server 2 sends to User B via WebSocket

**Decision 3: Persistence Strategy**
- **Approach 1:** Save on every draw → Too many DB writes
- **Approach 2:** Save on disconnect → Lose data if server crashes
- **Chosen:** Auto-save every 5 seconds to MongoDB
- **Recovery:** Load from DB on reconnect

**Data Model:**
```
WhiteboardSession {
  sessionId: unique identifier
  problemId: which problem being discussed
  participants: array of user IDs with roles
  elements: Excalidraw drawing data
  createdAt, updatedAt
}
```

---

## 🔐 Security Architecture - Defense in Depth

### 6 Layers of Security

**Layer 1: Network Perimeter**
- CloudFlare DDoS protection (unlimited)
- Rate limiting: 1000 requests/minute per IP
- TLS 1.3 encryption

**Layer 2: Load Balancer (Nginx)**
- Per-user rate limiting (100 req/min)
- Request size limits (10 MB max)
- Header validation & sanitization

**Layer 3: Authentication & Authorization**
- **JWT tokens:** HS256 algorithm, 7-day expiry
- **Session validation:** Every request checks Redis
- **RBAC:** User vs Admin permissions

**Layer 4: Input Validation**
- Code size limit: 10 KB (prevents DoS)
- Forbidden pattern detection:
  - `require('child_process')`
  - `import subprocess`
  - `Runtime.getRuntime().exec()`
  - `system()`, `eval()`

**Layer 5: Code Execution Sandbox (Judge0)**
- **Docker isolation:** Each submission in separate container
- **Resource limits:**
  - CPU time: 2 seconds max
  - Memory: 256 MB max
  - Processes: 30 max
- **Network:** Completely disabled
- **Filesystem:** Read-only (except /tmp)
- **Seccomp profiles:** Block dangerous syscalls

**Layer 6: Data Security**
- Encryption at rest: AES-256
- Password hashing: Bcrypt (10 rounds)
- Secrets: AWS Secrets Manager
- Database backups: Daily full + 6h incremental

**Why 6 Layers?**
If an attacker bypasses one layer, 5 more remain. Single points of failure = bad.

---

## 📊 Scalability: Handling 10,000 Concurrent Users

### Horizontal Scaling Strategy

**Kubernetes HPA (Horizontal Pod Autoscaler):**
```
Configuration:
- Min replicas: 3 (high availability)
- Max replicas: 20 (resource management)
- Scale up: CPU > 70% OR Memory > 80%
- Scale down: CPU < 40% for 5 minutes
```

**Why Kubernetes?**
- Auto-healing (pod crashes → restart)
- Rolling updates (zero downtime deploys)
- Resource management (CPU/memory limits)
- Service discovery (automatic DNS)

### Database Scaling Strategy

**MongoDB (Primary Database):**
```
Architecture: Replica Set (PSS)
- 1 Primary (us-east-1) → All writes
- 1 Secondary (us-west-1) → Read queries
- 1 Secondary (eu-west-1) → Read queries

Read Preference: secondaryPreferred (40% load on each secondary)
Write Concern: majority (data safety)

Future: Shard when > 10M documents
Shard Key: { userId: "hashed" } for even distribution
```

**PostgreSQL (Analytics):**
```
Architecture: Master-Replica
- Master: All writes (metrics, logs)
- Replica 1: Analytics queries
- Replica 2: Reporting dashboards

Extension: TimescaleDB for time-series optimization
Use case: User activity over time, submission trends
```

**Redis (Cache & Pub/Sub):**
```
Architecture: Cluster (3 nodes)
- Node 1: Master (cache + sessions)
- Node 2: Replica (failover)
- Node 3: Replica (failover)

Persistence: RDB snapshots (5 min) + AOF
Max Memory: 4 GB
Eviction Policy: allkeys-lru (least recently used)
```

### Worker Scaling

**BullMQ Queue Configuration:**
```
Code Execution Queue:
- Min workers: 5
- Max workers: 50
- Concurrency: 10 jobs per worker
- Scale trigger: Queue depth > 100

AI Avatar Queue:
- Min workers: 2
- Max workers: 20
- Concurrency: 5 jobs per worker
- Scale trigger: Queue depth > 50

Visualizer Queue:
- Min workers: 2
- Max workers: 15
- Concurrency: 5 jobs per worker
```

**Math Check:**
```
Peak Load: 1,000 submissions/minute
         = 16.7 submissions/second

Average execution time: 2 seconds

Required concurrent workers:
16.7 submissions/sec × 2 sec = 33.4 workers

Configured max: 50 workers
Headroom: 50 - 34 = 16 workers (47% buffer) ✓
```

---

## 🗄️ Data Architecture Decisions

### Why MongoDB for Primary DB?

**Pros:**
✅ Flexible schema (problems have varying test cases)
✅ Horizontal scaling with sharding
✅ Rich query language (filter by difficulty, tags, companies)
✅ Replica sets for HA

**Cons:**
❌ Weaker transactions (fixed in 4.0+)
❌ Larger storage footprint

**Use Cases:**
- Problems collection (155+ documents)
- Submissions collection (millions of documents)
- Whiteboard sessions

### Why PostgreSQL for Analytics?

**Pros:**
✅ ACID transactions
✅ Complex joins for user analytics
✅ TimescaleDB for time-series optimization
✅ Better for aggregations

**Use Cases:**
- Submission analytics (success rate over time)
- User activity logs
- Leaderboard snapshots

### Why Redis?

**Pros:**
✅ Sub-millisecond latency
✅ Sorted Sets for leaderboards (O(log N) operations)
✅ Pub/Sub for WebSocket scaling
✅ Built-in TTL for sessions

**Use Cases:**
- Session storage (7-day TTL)
- Problem caching (1-hour TTL)
- Leaderboard (Redis Sorted Set)
- WebSocket pub/sub

**Leaderboard Implementation:**
```
Data Structure: Redis Sorted Set
Command: ZADD leaderboard:contest123 <score> <userId>
Retrieve Top 100: ZREVRANGE leaderboard:contest123 0 99 WITHSCORES

Time Complexity: O(log N)
Handles: 10K users × 5-second polling = 2K QPS easily
```

---

## 🎯 Architecture Decisions Explained

### Decision 1: Why BullMQ Over AWS SQS?

**Comparison:**

| Feature | BullMQ (Redis) | AWS SQS |
|---------|----------------|---------|
| Latency | < 10ms | 50-100ms |
| Priority Queues | ✅ Native | ❌ Separate queues |
| Retry Logic | ✅ Built-in | Manual |
| Local Dev | ✅ Easy | ❌ Need AWS account |
| Infrastructure | Uses existing Redis | Additional service |

**Chosen:** BullMQ for lower latency and simpler infrastructure.

### Decision 2: Why Socket.io Over Native WebSocket?

**Socket.io Advantages:**
- ✅ Automatic fallback (WebSocket → long polling)
- ✅ Reconnection logic built-in
- ✅ Room-based messaging
- ✅ Cross-platform (web + mobile)

**Trade-off:** Slightly larger bundle size, but better compatibility.

### Decision 3: Why Next.js Over Pure React?

**Next.js Benefits:**
- ✅ Server-side rendering (better SEO)
- ✅ API routes (no separate Express for simple endpoints)
- ✅ Image optimization
- ✅ Automatic code splitting

**Use Case:** Problem listing page needs SEO for Google.

### Decision 4: Why Separate PostgreSQL for Analytics?

**Why Not Just MongoDB?**
- MongoDB aggregations are slower for complex queries
- PostgreSQL better for JOINs (users + submissions + problems)
- TimescaleDB optimizes time-series queries (activity over time)

**Trade-off:** More complexity (2 databases) but better performance.

---

## 🚀 Performance Metrics

**Achieved SLA:**
- ✅ Code execution: < 3s (p95)
- ✅ Page load: < 2s
- ✅ API latency: < 500ms (p95)
- ✅ WebSocket latency: < 100ms
- ✅ Cache hit rate: > 70%
- ✅ Uptime: 99.9% (43 minutes downtime/month allowed)

**How We Measure:**
- Prometheus for metrics collection
- Grafana for dashboards
- Sentry for error tracking
- ELK Stack for log aggregation

---

## 🎓 Key Learnings

### 1. Async Processing is Non-Negotiable

**Early Mistake:**
I initially tried synchronous code execution. When 1000 submissions/minute hit, API servers timed out.

**Solution:**
BullMQ job queue with auto-scaling workers. Now:
- API responds instantly with "submitted"
- Worker processes in background
- WebSocket notifies user when done

### 2. Caching is Critical for Performance

**Without Caching:**
- Every problem fetch → MongoDB query
- Every avatar question → 30-second generation time

**With Caching:**
- 85% problem queries served from Redis
- 70% avatar videos served from cache
- **Result:** 80% reduction in MongoDB load, instant response for cached queries

### 3. Security in Layers, Not Walls

**Wrong Approach:**
"If our firewall is strong, we're safe."

**Right Approach:**
6 layers of defense. If one fails, 5 remain.

Example: Even if attacker bypasses rate limiting (Layer 1-2), they hit:
- JWT validation (Layer 3)
- Input sanitization (Layer 4)
- Docker sandbox (Layer 5)

### 4. Monitor Before You Scale

**Built Monitoring First:**
- Prometheus metrics from day one
- Grafana dashboards before launch
- Sentry error tracking in alpha

**Why?** You can't optimize what you can't measure. Without metrics, scaling is guesswork.

---

## 🔮 Future Improvements

### Technical Debt to Address

1. **Self-host Judge0**
   - Current: Using Judge0 API
   - Plan: Docker on Kubernetes for better control
   - Benefit: More flexibility in resource allocation

2. **Multi-region Deployment**
   - Current: Single region (us-east-1)
   - Issue: High latency for Asia/Europe users
   - Plan: CloudFlare Workers + edge caching

3. **Database Sharding**
   - Current: Single MongoDB replica set
   - Trigger: When > 10M submissions
   - Strategy: Shard by userId (hashed)

4. **GraphQL API**
   - Current: REST with over-fetching
   - Benefit: Reduce data transfer by 40%

---

## 🤔 Questions I'd Ask Myself in System Design Interview

**Q: Why not use AWS Lambda for code execution?**
A: Lambda has 15-minute timeout, cold starts add latency. Judge0 in Docker has consistent performance and better resource limits.

**Q: Why MongoDB AND PostgreSQL? Why not just one?**
A: Different workloads. MongoDB excels at flexible schemas and horizontal scaling. PostgreSQL excels at complex analytics. Multi-database is common in microservices.

**Q: How do you prevent one user from DDoSing your platform?**
A: Rate limiting at 3 levels - CloudFlare (per IP), Nginx (per user), Application (per API endpoint). Plus BullMQ queue prevents worker overload.

**Q: What happens if Redis goes down?**
A: 3-node cluster with automatic failover. If all nodes fail: Sessions lost (users re-login), cache miss (MongoDB serves requests), WebSocket disconnects (auto-reconnect). Not ideal, but platform stays up.

**Q: Why 99.9% uptime and not 99.99%?**
A: Trade-off between availability and complexity. 99.9% = 43 min/month downtime (acceptable for coding practice). 99.99% requires multi-region deployment with significantly more infrastructure complexity.

---

## 📖 Recommended Reading

If you're designing a similar system:

**Books:**
- "Designing Data-Intensive Applications" by Martin Kleppmann
- "System Design Interview" by Alex Xu

**Resources:**
- [LeetCode System Design (HelloInterview)](https://www.hellointerview.com/learn/system-design/problem-breakdowns/leetcode)
- [MongoDB Sharding Guide](https://www.mongodb.com/docs/manual/sharding/)
- [Redis Sorted Sets for Leaderboards](https://redis.io/commands/zadd/)

---

## 🎯 Conclusion

Building CodeNova taught me that **good architecture is about trade-offs**, not perfection.

**Key Takeaways:**
1. **Async everything** - Queues are your friend
2. **Cache aggressively** - Improves performance and reduces load
3. **Security in layers** - Defense in depth
4. **Measure first, optimize second** - Metrics before scaling

The architecture diagram isn't just boxes and arrows - it represents:
- Hundreds of hours of research
- Dozens of failed experiments
- Lessons from production incidents

**If I were to start over**, I'd:
- ✅ Build monitoring first (kept this)
- ✅ Use queues from day one (learned this the hard way)
- ✅ Start with fewer databases (added PostgreSQL later)
- ❌ Not self-host initially (buy before build)

---

## 💬 Discussion

**How would you design this differently?**

Would you use:
- Serverless (Lambda) instead of Kubernetes?
- GraphQL instead of REST?
- DynamoDB instead of MongoDB?
- Different AI providers?

Drop your thoughts in the comments! 👇

I'm especially interested in:
- Better ways to optimize AI response generation
- Better ways to scale WebSockets
- Alternative code execution sandboxes

---

**Built with ❤️ and lots of ☕ by Bhupesh Chikara**

---

#systemdesign #architecture #webdev #ai #mongodb #kubernetes #redis #postgresql #websocket #nodejs #react #typescript #microservices #cloudcomputing #devops


TL;DR   I designed and built CodeNova, a scalable coding interview platform handling 10K+...

Building CodeNova: System Design Deep Dive into an AI-Enhanced Coding Platform

Bhupesh Chikara

Hey Devs! 👋

Heard of the "CAP theorem" in system design? It sounds academic, but it's crucial for distributed systems (like microservices or multi-server databases). This post breaks CAP down simply. Let's go!

## 🤔 What is the CAP Theorem?


![CAP Theorem](https://dev-to-uploads.s3.amazonaws.com/uploads/articles/vmotz3rmdmshnx2jgeuu.png)


The CAP theorem (or Brewer's theorem) is key for distributed data stores. It states **a distributed system can't guarantee all three simultaneously**:

* **C**onsistency
* **A**vailability
* **P**artition Tolerance

Understanding these trade-offs is vital for good design.

## 🧐 Breaking Down "CAP"


![CAP Theorem Overall Trade-off](https://dev-to-uploads.s3.amazonaws.com/uploads/articles/puiv2f3nbe08xyfpwwhx.png)


### **C**onsistency: All Nodes See the Same Data, Now

All reads get the most recent write or an error. After a write, all nodes reflect that update, giving users a unified data view.
* *Analogy:* A shared doc where everyone instantly sees the latest saved version.

### **A**vailability: Every Request Gets a Response

Every request to a working node gets a response. The system is operational, though responses might not always have the absolute latest data.
* *Analogy:* An online store that's always open, even if product info occasionally has a slight delay in updating everywhere.

### **P**artition Tolerance: System Works Despite Network Issues

The system works despite network communication failures between nodes (e.g., due to a failed switch or cable).
* *Analogy:* Office branches operating independently when their network connection drops, then syncing later.

**Why Partition Tolerance is Key:**

Network failures (partitions) are inevitable in distributed systems. Thus, **P**artition Tolerance is essential; without it, systems become unreliable during glitches. So, **most distributed systems need partition tolerance**.

## ⚖️ The Core Trade-off: CP vs. AP


![CP vs AP Systems Trade-off](https://dev-to-uploads.s3.amazonaws.com/uploads/articles/vhqbfg8i29266jqus9hb.png)


Since Partition Tolerance (P) is usually required, the main CAP trade-off during a partition is between Consistency (C) and Availability (A).

### **CP Systems (Consistency + Partition Tolerance)**

Prioritize consistency during partitions. If data can't be verified as current, the affected part of the system may become unavailable (refusing writes/reads) to prevent inconsistency.
* *Use Cases:* Financial systems, inventory management—where accuracy trumps constant uptime.

### **AP Systems (Availability + Partition Tolerance)**

Prioritize availability during partitions. The system stays operational, even if it means some nodes serve slightly older data (eventual consistency) until the partition resolves.
* *Use Cases:* Social media, e-commerce listings—where high availability is key, and slight data staleness is acceptable.

## 🌈 Nuances to CAP

* **Not just 2 of 3:** Real systems have nuanced behaviors; choices aren't always absolute.
* **Latency matters:** Operation speed is critical beyond CAP guarantees.
* **Eventual Consistency:** Common in AP systems; data eventually becomes consistent if no new updates occur.
* **Context is King:** The best CP/AP choice depends on your app's needs (e.g., banking: **CP**; social feeds: **AP**).

## 🎁 Wrapping Up

CAP isn't about achieving all three guarantees—it's a model for understanding vital trade-offs in distributed systems. Knowing C, A, and P helps you make informed design choices. Keep CAP in mind when architecting or choosing distributed databases.

Share your CAP experiences in the comments! 👇


Hey Devs! 👋  Heard of the "CAP theorem" in system design? It sounds academic, but it's crucial for...

My Articles

Building CodeNova: System Design Deep Dive into an AI-Enhanced Coding Platform

The CAP Theorem: Why Consistency, Availability, and Partition Tolerance Can't All Be Friends
